The barge is now ready to be transported across the Bristol Channel to Hinkley Point C

Hinkley Point C gears up for summer of heavy lifting

By EDF | Posted July 12, 2022

Hinkley Point C is getting ready for another spectacular engineering feat with the precision placement of 5,000 tonne cooling-water intakes on the seabed.

Four times longer and twice as high as a double-decker bus, each intake head will be connected to five miles of tunnels used to circulate cooling-water for the new power station.

The first heads have been carefully loaded onto barges at Bristol Port’s Avonmouth docks, ready to be towed out to meet two floating heavy lift cranes “Gulliver” and “Rambiz” which will work in tandem to lower the structures into place. Each platform is the size of a football pitch and the cranes have a combined lifting capacity of 7,300 tonnes.
The four “intake” and two “outfall” heads have been built by Balfour Beatty in Avonmouth. Each “loading out” operation, carried out by lifting specialists Mammoet, takes several hours, with the water levels being adjusted at the dock, to ensure the barge can receive the load safely and securely.

Ian Beaumont, Project Director Marine Civils at Hinkley Point C said: “This starts a summer of complex offshore operations, with teams working in collaboration to deliver an incredible feat of engineering. It demonstrates the continued progress being made at Hinkley Point C.”

Roger Frost, Project Director at Balfour Beatty, said: “Today marks yet another exciting milestone in the construction of Hinkley Point C with the arrival of some of the largest heavy lift vessels in the world, on site. We are now readying ourselves to successfully complete our next feat of engineering: lowering the head structures, which will support the nuclear power station's critical water-cooling system, to the very bottom of the Bristol Channel.”

The structures will cap the tunnels which will supply Hinkley Point C’s two nuclear reactors with cooling water. The heads are big for a reason. Their size means water will enter the intakes slowly, reducing the number of fish entering the cooling pipes. They are also placed sideways to the tidal flow.  In addition, screens and a fish return system will transfer fish back to sea.

Hinkley Point C will be the first power station around the Bristol Channel to have fish protection measures in place.






Notes for editor:

The worst case predicted effect of Hinkley Point C with the planned two fish protection measures in place varies by species, from a maximum of 0.2% to less than 0.001% per year. Cefas concluded that this level is negligible compared with natural mortality and fishing. The predicted levels will have no effect on the sustainability of each species nor on the predators that rely on the fish to survive.

Power stations around the Bristol Channel have taken water for decades – all without any fish protection measures. When Hinkley Point C comes into operation water use will be no higher than the late 1990s and, for the first time, fish protection measures will be in place.


Downloads

The operation to load a 5,000 tonne intake head onto a barge takes several hours
The operation to load a 5,000 tonne intake head onto a barge takes several hours
The water in the dock is adjusted several times, to ensure the barge can receive the load securely
The water in the dock is adjusted several times, to ensure the barge can receive the load securely
The barge breaks away from the dock, and is guided by towing boats to its next mooring spot
The barge breaks away from the dock, and is guided by towing boats to its next mooring spot
The barge is now ready to be transported across the Bristol Channel to Hinkley Point C
The barge is now ready to be transported across the Bristol Channel to Hinkley Point C
Gulliver arriving in the Bristol Channel just off of Hinkley Point C site
Gulliver arriving in the Bristol Channel just off of Hinkley Point C site
The intake head being carefully manoeuvred onto the barge.
The intake head being carefully manoeuvred onto the barge.
Gulliver arriving in the Bristol Channel just off of Hinkley Point C site
Gulliver arriving in the Bristol Channel just off of Hinkley Point C site
